Gemtech Differential Pressure Gauge Range 0-20 Kilopascals Coimbatore, Tamil Nadu
Having Vast Experience in The Relevant Industries,We Are Engaged in Providing a Broad Assortment of GEMTECH Gauge that is assemble in order to meet specific Demands of Customers. Moreover, a series of quality tests is performed on offered gauge to ensure a defect free delivery at client’s end. Clients can avail the Offered Range From us at Market Leading Prices within Stipulated time Frame.
Features:
Accuracy
High functionality
Long service life
Specifications:
We provide GEMTECH Magnehelic Gauge of series which is low in cost,diaphragm operated and differential pressure gauge
Owing to these features these are used in applications for measuring positive, negative, or differential pressure with an accuracy of 2%
Besides,these are also applied for monitoring filter status, duct static pressure, room pressure, fan or blower pressure, paint booths, dust collectors, cabinet purging and many others
We offer GEMTECH magnehelic differential pressure gauges which run on air and non-combustible compatible gases and are offered with the option of natural gas
In addition to this, these housing are fabricated by using die cast aluminum case and bezel, with acrylic cover
These have exterior finish with grey color to withstand 168 hour salt spray corrosion test
Technical Specifications:
Accuracy: ±2% of full scale (±3% on – 0, -100 Pa, -125 Pa, 10MM and ±4% on – 00, -60 Pa, -6MM Ranges), Throughout Range at 70°F (21.1°C)
Pressure Limits: -20 Hg. To 15 PSIG.† (-0.677 Bar to 1.034 Bar); MP Option
HP Option: 35 PSIG (2.41 Bar), 80 PSIG (5.52 Bar)
Over Pressure: Relief Plug Opens At Approximately 25 PSIG (1.72 Bar), Standard Gages Only
Temperature Limits: 20 to 140°F.* (-6.67 to 60°C)
Size: 4 (101.6 MM) Diameter Dial Face
Mounting Orientation: Diaphragm In Vertical Position, Consult Factory For
Process Connections: 1/8 Female NPT Duplicate High And Low Pressure Taps One Pair Side And One Pair Back
Weight: 1 lb 2 oz (510 g), MP & HP 2 lb 2 oz (963 g)
Other Position Orientations
Applications:
Filter Status
Duct Static Pressure
Clean Room Pressure
Building Pressure
Fan and Blower Pressure
Paint Booths
Dust Collectors
Glove Box Pressure
Bubbler Systems
Cabinet Purging
GEMTECH Differential Pressure Gauge Range 50-0-50 Pascal Kochi, Kerala
GEMTECH Differential Pressure Gauge Range 0-10 MM Balangir, Odisha
GEMTECH Differential Pressure Gauge Ajmeri Gate Delhi
GEMTECH Differential Pressure Gauge Rupnagar, Punjab
GEMTECH Differential Pressure Gauge Ahmedabad,Gujarat
GEMTECH Differential- Pressure Gauge Buldhana, Maharashtra
GEMTECH Differential- Pressure Gauge Kolkata, West Bengal
GEMTECH Differential- Pressure Gauge Nawalgarh, Rajasthan
GEMTECH Differential- Pressure Gauge Muzaffarnagar,Uttar Pradesh
GEMTECH Differential- Pressure Gauge Indore, Madhya Pradesh
GEMTECH Differential Pressure Gauge - Aizawl Mizoram
Gemtech Differential pressure Gauges - Hapur Uttar Pradesh
Gemtech Differential pressure Gauges - Bolangir Odisha
Gemtech Differential pressure Gauges - Jaipur Rajasthan
Gemtech Differential pressure Gauges Range 0 to 50 inch
GEMTECH Differential Pressure Gauge Range 0-2.5 Kilopascal
GEMTECH Differential pressure Gauges Range 0-10 Inch
GEMTECH Differential pressure Gauges Range 0 -100 Pascal
Gemtech Differential pressure Gauges - Kodavasal Tamil Nadu
Gemtech Differential pressure Gauges- Faridabad Haryana
GEMTECH -Differential Pressure Gauge Kodavasal Tamil Nadu
GEMTECH Differential Pressure Gauge form Tirupur Tamil Nadu
Gemtech Differential pressure - Gauges Range 0-30 Pascal
Gemtech Differential pressure Gauges | Range 6-0-6 mm
Gemtech Differential pressure Gauges | Libaspur Industrial area Delhi
Gemtech Differential - pressure Gauges Range 0-60 Pascal
Gemtech Differential pressure Gauges - Hauz Qazi Chowk Delhi
GEMTECH Differential Pressure Gauge - Bijnor Uttar Pradesh
GEMTECH Differential Pressure Gauge - Shajapur Madhya Pradesh
GEMTECH Differential Pressure Gauge - Panvel Maharashtra
Gemtech Differential pressure Gauges - Kolhapur Maharashtra
Gemtech Differential pressure Gauges - Hyderabad Telangana
Gemtech Differential pressure Gauges - Bhongaon Uttar pradesh
Gemtech Differential pressure Gauges - Darya Ganj
Gemtech Differential pressure Gauges Range 0-5 Kilopascal
GEMTECH Differential Pressure Gauge - Mumbai Maharashtra
GEMTECH Differential Pressure Gauge - Nandyal Goa
Gemtech Differential pressure Gauges- wholesale Dealers Range 0 to 10 mm wc
Gemtech-Differential pressure Gauges wholesale Dealers Range 0 to 50 mm wc
Gemtech - Differential pressure Gauges wholesale Dealers Range 0 to 100 Pascal
Gemtech - Differential pressure Gauges wholesale Dealers Range 0 to 60 Pascal
Model G2300-12MM Gemtech Differential pressure Gauges Range 6-0-6 mm wc
G2300 -20MM Gemtech Differential pressure Gauges - Range 10-0-10 mm wc
Model G2300-150 CM Gemtech Differential pressure Gauges Range: 0-150 CM wc
Model G2300-15 CM Gemtech Differential pressure Gauges Range: 0-15 CM wc
Model G2300-20 CM Gemtech Differential pressure Gauges Range 0-20 CM wc
Model G2000-500 Pa Gemtech Differential Pressure Gauges Range: 0 To 500 Pascal
GEMTECH Series G2000-6 MM Differential Pressure Gauges - Range 0 to 6 MM WC
GEMTECH Series G2000-250 MM-Differential Pressure Gauges Range:0 to 250 MM WC
Gemtech - Differential Pressure Gauges Range 0-250 mm Thiruvananthapuram Kerala
GEMTECH Series G2000-250 MM Differential -Pressure Gauges Range : 0 to 250 MM WC
Gemtech G2015 Differential- Pressure Gauges Range 0 to 15 Inch
Gemtech Series G2000-200MM - Differential Pressure Gauges Range 0 to 200 MM WC
Mechanical Sifter Sieves: - Sieves for mech. shifter size of 20” and 30” and mesh size as per clients choice. In big sizes supports are provided for the rigidity and stiffness.
We manufacture SS Sifter Sieves in SS 304 and SS 316 with Silicon Molded / without Silicon molded .
We are engaged in offering our clients with a qualitative range of Pharma Sifter Sieves. These are offered in diameters of 20, 30, 40, and 48 inches and also as per the drawings from 4 meshes to 500 meshes with additional cross support of 18 SWGS. Our range is cross welded to the bottom of the ring with additional sieves. This supports sieves as per customer specifications and we also silicon mould sifter sieves using SS 316/304.
Mesh Nos |
Mesh Nos |
Indian Std |
Microns |
4 | 5 | 4.00mm | 4000 |
5 | 6 | 3.35mm | 3353 |
6 | 7 | 2.80mm | 2812 |
7 | 8 | 2.36mm | 2411 |
8 | 10 | 2.00mm | 2057 |
10 | 12 | 1.70mm | 4000 |
12 | 14 | 1.40mm | 1405 |
14 | 16 | 1.18mm | 1204 |
16 | 18 | 1.00mm | 1204 |
18 | 20 | 0.850mm | 850 |
22 | 25 | 0.710mm | 710 |
25 | 30 | 0.600mm | 600 |
30 | 35 | 0.500mm | 500 |
36 | 40 | 0.425mm | 420 |
44 | 45 | 0.355mm | 355 |
52 | 50 | 0..300mm | 300 |
60 | 60 | 0.250mm | 250 |
72 | 70 | 0.212mm | 210 |
85 | 80 | 0.180mm | 180 |
100 | 100 | 0.150mm | 150 |
